Basic Information
Panel Size: 15.6 inch, Model: YF-I156GC1, Panel manufacturer: CSOT/BOE/AUO/other, Panel type: VA, Number of Pixels: 1920*1080, Active Area: 344.16 (H) * 193.59 (V), Surface Treatment: Anti-Glare and Hard-coating 3H, Display Mode: Normally Black, Luminance（white）: 250cd/㎡, Contrast ratio: 3000:1, Response time: 30ms, TOUCH: 10 points capacitive touch,
Specification
Scaner: 1D&2D, Screen scale: 16:9, Viewing Direction: 89/89/89/89, Refresh frequency: 60HZ, Display Color: 16.7M, System: Android 11, CPU: RK3568 Quad-core Cortex-A55, Memory: 4GB, Storage: eMMC 32GB, Ethernet: 1 * Realtek GbE LAN Chip (RJ45, 10/100/1000 Mbps), Power Supply: DC12V Power Input / AC 220V Input, Wireless Module: Support Wi-Fi 2.4/5GHz Frequencies and Bluetooth 4.2 (support BLE),
Interface Type
USB2.0: USB typeA, USB 3.0: USB typeA, Micro USB2.0: Micro USB, TF: TF CARD, LINE OUT: Audio out, AC: AC 220V Input, RJ45: RJ45, WIFI: Support Wi-Fi 2.4/5GHz（opention）, Bluetooth: Bluetooth 4.2（opention）, Key mode: NC, Appearance Material: Metal, Appearance color: Black, Apparent dimension: 408*296.4*77mm, Net weight: 6.0kg, Speaker: 5W*2(8Ω), Power dissipation: "On: ≤50W, Standby≤0.5W, Off≤0.5W" VESA: 100*100mm, Temperature and humidity: 0ºC~50ºC 10～85%RH non-condensing, Remarks: "Customer's other special requirements can be based on the actual Order demand to increase or decrease"
