Specification
Model: YF-I215GZ3, Panel Size: 21.5 inch, Panel manufacturer: CSOT/BOE/AUO/other, Panel type: VA, Number of Pixels: 1920*1080, Active Area: 476.64(H) ×268.11 (V) mm, Surface Treatment: Anti-Glare and Hard-coating 3H Display Mode: Normally Black, Luminance（white）: 250cd/㎡, Contrast ratio: 3000:1, Response time: 30ms TOUCH: 10 points capacitive touch, Scaner: 1D&2D, Screen scale: 16:9, Viewing Direction: 89/89/89/89, Refresh frequency: 60HZ, Display Color: 16.7M, System: Android 11, CPU: RK3568 Quad-core Cortex-A55, Memory: 4GB, Storage: eMMC 32GB, Ethernet: 1 * Realtek GbE LAN Chip (RJ45, 10/100/1000 Mbps), Power Supply: DC12V Power Input / AC 220V Input, Wireless Module: Support Wi-Fi 2.4/5GHz Frequencies and Bluetooth 4.2 (support BLE)
Interface Type
Interface type: USB2.0 USB typeA*5, DC12V-OUT: DC5.5*2.5mm*2, DC12V-OUT: UB11123-GHT2-4F *3, DC24V-OUT: UBA1123-GT181-4H *1, USB 3.0: USB typeA, Micro USB2.0: Micro USB, TF: TF CARD, LINE OUT: Audio out, AC: AC 220V Input, RJ45: RJ45, WIFI: Support Wi-Fi 2.4/5GHz（TBD), Bluetooth: Bluetooth 4.2（TBD）, KEY: Key mode NC, Appearance weight: Appearance Material: Metal, Appearance color: White, Apparent dimension: L776*W368*H155mm（TBD）, Net weight: 6.0kg（TBD）, Hardware function: Speaker: 5W*2(8Ω), Power dissipation: "On: ≤150W, Standby≤0.5W, Off≤0.5W", VESA: 291*125mm, Working environment: Temperature and humidity: 0ºC~50ºC 10～85%RH non- condensing, Remarks: "Customer's other special requirements can be based on the actual, Order demand to increase or decrease"
